SNOL 3/320

Low temperature resistive electric oven SNOL 3/320 is a dry storage container intended for drying, dry storage or transportation of welding electrodes.

BASIC MODEL

  • Maintains до 10 kg of 45 cm electrodes;
  • 2 containers for electrodes storage are inside;
  • Температура range + 60-+320 C, temperature is adjustable;
  • Exterior is treated and painted with a powder paint RAL 7035 (abrasion and corrosion resistant finish);
  • Durable Steel construction means long product life;
  • Oven is comfortable for transportation;
  • Fitted wheels and handle help to transport electric oven and place it to the right place in the work area;
  • Thermal insulating wool makes oven energy efficient, keeps electrodes hot and moisture-free.

Specification

Технічні характеристики Dimension  SNOL 3/320
Корисний об'єм Liter 3
Номінальна потужність не більше kW 1.0
Номінальна напруга живлення V 230
Номінальна частота Hz 50
кількість фаз - 1
Rated temperature °C 320
Atmosphere in the chmber - Air
Maximum heating- up time (without charge) Min. 15
Furnace working chamber dimensions:
width mm mm 100
length mm mm 500
height mm mm 125
Furnace external dimensions:
width mm mm 230
length mm mm 740
height mm mm 435
Weight kg 12
